I have updated my code to Read data from a Bosch BMP085 with a Raspberry Pi to correct some bugs reported back to me.

The main bug was that I’d forgotten to close the i2c file at the end of bmp085_ReadUP() – This shouldn’t have caused any problems if you were calling the function once per execution, but if calling it multiple times, it may crash. On the same note, if you are calling the functions multiple times, you may want to move the opening and closing of the i2c file outside of the functions so the files aren’t opened and closed multiple times. Thanks to Radu P for reporting these issues.

It looks like lm-sensors.org is back up now, but if not, you can find a locally hosted copy of smbus.c and smbus.h in this earlier blog post.

Note that I’ve written a number of posts on using this sensor. Here is a link to all posts on the topic.
(more…)

Our water at home is supplied by way of rainwater off the roof of the house. We have about 55000 Litres (~14500 Gallons) of storage capacity but a long dry summer sees the levels drop considerably.

I decided it was time to add a water meter into the circuit to be able to monitor our water usage.

I picked up an Elster S100 water meter complete with an electronic Pulse output.

The meter outputs one pulse per Litre of water. It’s only a two wire output so it appears to be a simple switched output such as that from a reed switch, but I’ll need to check before committing to any specific circuit design.

I’ll Probably use an Atmel AVR Microcontroller to count the pulses. The AVR will be setup as an SPI Slave to talk to a Raspberry Pi. I should have a better idea how best to implement it soon.

Since my earlier post on Reading data from a Bosch BMP085 with a Raspberry Pi, the lm-sensors.org website has gone down.

If you need smbus.c or smbus.h, here are copies from back in August 2012.

Note that I have made some changes to smbus.c:

• Defined NULL
• Changed the path for including smbus.h

Here are the two files:

• smbus.c
• smbus.h

After a few comments regarding my code to read data from a Sensirion SHT1x with a Raspberry Pi, I’ve got some updated code.

Please see my previous post for general information, but use the code here.

The list of changes are:

• Added Dewpoint calculation from Page 9 of Datasheet
• Updated Humidity calculation Coefficients to recommended (12 bit) figures from Page 8 of Datasheet
• Updated Temperature calculation Coefficients to recommended (3.3 Volt Interpolated) figures from Page 9 of Datasheet

Any references to the datasheet refer to the Version 5, Dec 2011 datasheet found on Sensirions website.

Also note that the bcm2835 GPIO library has been updated and is now version 1.8 – Get the updated version from http://www.open.com.au/mikem/bcm2835/.
(more…)

Last week I wrote about how to bypass the USB Polyfuses on the Raspberry Pi to Increase the available power for USB devices.

Unfortunately, my Raspberry Pi is still unstable (I’ve tried both Raspian and ARCH Linux), so I’m playing around a lot with increasing the USB power capability.

The next option, which will definitely void the warranty is to completely remove the Polyfuses and run power direct from the DC input to the USB ports. This bypasses all the fuses on the board and replaces the thin PCB traces with a heavier gauge wire.

Without fuses, you could get into trouble if you don’t know what you’re doing. Consider yourself warned!

Here’s how to do it.

First, remove the USB Polyfuses from the Raspberry Pi.

Raspberry Pi with USB Polyfuses removed

I bought a Logitech C920 webcam last week. It’s a very nice unit which outputs Full HD (1920×1080) video. The picture is really clear but it draws more power than the Raspberry pi can supply.

For me this power problem affects my network connection. It seems that the Network adapter is very picky when it comes to it’s supply voltage.

The Webcam seems to draw about 240mA at 5 volts when it focuses, while the Raspberry Pi is limited to 140mA per USB port and 1.1A total current draw.

The Raspberry Pi limits these currents by way of Polyfuses which are a fuse made of a special polymer. They “blow” like a fuse if too much current goes through them, but then over time “heal” and conduct again. Unfortunately due to their inherit design, before they “blow” their resistance increases as the current increases. This can cause a drop in voltage, commonly referred to as voltage droop.

Without going into too much more detail, this basically means that as a USB device approaches a 140mA current draw, the voltage going to the device will drop and in much that same way, if the total current approaches 1.1 Amps, the system voltage will drop.

I decided the best way to fix this problem is to bypass the Polyfuses on the USB port with wire links. This would mean that the 140mA limit was bypassed, but the total 1.1 Amp limit would still apply. Note that this more than likely voids the warranty on your Raspberry Pi.

You first need to find the PolyFuses on your Raspberry Pi. They are easy to find, they’re the two green “blocks” on the board between the USB port header and the activity LEDs.

Photo showing the Polyfuses (Green blocks) protecting the USB ports.

I’ve previously documented the protocol of the La Crosse TX20 Anemometer, but mine recently failed.

The La Crosse TX23U Anemometer is almost half the price of the TX20, so I decided to buy one and see if I could decode the protocol.

The big difference between the TX20 and the TX23U is that the TX20 will send a datagram every two seconds (when the DTR line is pulled low), while the TX23U won’t send anything until triggered by briefly pulling the Data line low.

Here’s everything you’ll ever want to know about the pin out and the communications protocol of the La Crosse TX23.
(more…)

Here’s a video of the Egg Turner running at full speed.

I definitely need to slow it down!

After a recent disaster when a broody chicken stopped being broody before the eggs hatched, I’ve decided to build a fully automated incubator.

The incubator will include:

• Temperature Control
• Humidity Control
• Automatic Egg Turning

The first step was to find a suitable enclosure so that the size of the Egg Turner could be determined. I decided to use a plastic storage box as this should be easy to clean after use. The plastic box will end up inside a plywood box for insulation.

I determined that based on the size of the box, I should have the space to turn 30 eggs in three rows of 5×2 eggs.

A few quick tests of Radio Control Servos quickly proved that they had enough torque and stroke to turn the eggs so an old Hitec servo was chosen as the drive system.

I got hold of some aluminium corner, a rivet gun and a few other essentials and in no time (actually about 20 hours) had it working.

I didn’t take any photos of it prior to completion, but here are some photos of it completed.

(more…)
